ZH-130 Automatic Cartoning Machine
Product description
ZH130 Muliti-function packing mmachine is a new model machine which developed by our conpany accomplied through the advanced
technology of domestic and international.it is a high-tech product include light,eletric,air,motor.make a huge improvements the equipment
performance and work.achieved fase packing,and maintain a stable and reliable state when machine is fast running.
Performance feature
1. Systerm is programmable controlled by PLC£¬human mahine interface operation.frequency control,electric element.
2. All parts from famous brand of international or domestic.
3. Achieved automatic feeding .opening.stuffing ,sealing,waste picking etc.
4. Can be configure the hot melt glue machine.
Main technical parameters
ZH130 Muliti-function packing mmachine is a new model machine which developed by our conpany accomplied through the advanced
technology of domestic and international.it is a high-tech product include light,eletric,air,motor.make a huge improvements the equipment
performance and work.achieved fase packing,and maintain a stable and reliable state when machine is fast running.
Performance feature
1. Systerm is programmable controlled by PLC£¬human mahine interface operation.frequency control,electric element.
2. All parts from famous brand of international or domestic.
3. Achieved automatic feeding .opening.stuffing ,sealing,waste picking etc.
4. Can be configure the hot melt glue machine.
Main technical parameters
Encasing speed | 20-100box/min (Product related) | |
Box | Size | 250-350g/m2(Base on carton size) |
Dimension range (LxWxH) | (55-220)×(30-130)×(15-50)mm | |
Leaflet | Size | 55-65g/m2 |
Unfolded leaflet specification | (100-250) × (100-190)mm | |
Compressed air | Fold range | (1-4)Fold |
Working pressure | 0.5-0.7Mpa | |
Air consumption | 0.2m3/min | |
Power supply | 380V/220V 50Hz 1.5kw | |
Main power | 1.5Kw | |
Machine dimension (LxWxH) | 3400×1350×1450mm | |
Machine weight | 1400Kg |
